Galaxy S8+ SM-G955FD specifications

Jump to firmware

Samsung's Galaxy S8+ SM-G955FD specifications and features: this is a 6.2” (158.1mm) device with a QHD + 2960x1440 screen resolution. The phone is powered by the Exynos 8895 soc with a 2.3GHz Quad + 1.7GHz Quad configuration. Memory is 4GB, with the device offering 64GB (UFS 2.1) internal storage and up to 256GB of external memory. The Galaxy S8+ features Accelerometer, Barometer, Fingerprint Sensor, Gyro Sensor and Geomagnetic Sensor. Notable features include Samsung Pay (MST), Samsung KNOX, Bixby, Samsung Pay (NFC). The device measures 159.5 x 73.4 x 8.1 mm and weighs 173g.
Galaxy S8+ SM-G955FD

General Information

Model name
Galaxy S8+
Model Number
SM-G955FD
Model type
Phone
Color
Midnight Black, Orchid grey, Artic silver, Maple Gold, Coral Blue
Announced
2017, March
Released
2017, April

Physical Specifications

Dimensions
159.5 x 73.4 x 8.1 mm
Weight
173g
IP Rating
IP 68 : Totally protected against dust, Protected against the effect of immersion to 1.5m for up to 30 minutes.

Operating System

Operating System
Android v 7.0 (Nougat)

Network/Bearer

SIM
Dual
WiFi Only
No
SIM card size
Nano-SIM (4FF)
Network
2G, 3G, 4G/LTE
2G GSM
GSM850, GSM900, DCS1800, PCS1900
3G UMTS
B1 (2100), B2 (1900), B4(AWS), B5 (850), B8 (900)
4G LTE
3G TD-SCDMA: B34 (2010), B39 (1880) 4G FDD LTE: B1(2100), B2(1900), B3(1800), B4(AWS), B5(850), B7(2600), B8(900), B12(700), B13(700), B17(700), B18(800), B19(800), B20(800), B25(1900), B26(800), B28(700), B32(1500), B66(AWS-3)

Display

Technology (Main Display)
Super AMOLED
Size (Main Display)
6.2” (158.1mm)
Resolution (Main Display)
QHD + 2960x1440
Colour Depth (Main Display)
16M
Pixel Density
~529 PPI
Gorilla Glass
Version 5 Front & Back
Matrix
Diamond
S Pen Support
No

Processor

Type
Exynos 8895
Clock Speed
2.3GHz Quad + 1.7GHz Quad
Cores
8 Cores (Octa-Core)
GPU
Mali-G71 MP20

Memory

RAM Size (GB)
4GB
ROM Size (GB)
64GB (UFS 2.1)
SSD
No
eMMC
No
External Memory Support
Up to 256GB

Sensors

Sensors
Accelerometer, Barometer, Fingerprint Sensor, Gyro Sensor, Geomagnetic Sensor, Hall Sensor, Heart Rate Sensor, Proximity Sensor, RGB Light Sensor, Iris Sensor, Pressure Sensor
Additional features
Samsung Pay (MST), Samsung KNOX, Bixby, Samsung Pay (NFC)

Audio and Video

Video Recording Resolution
UHD 4K (3840 x 2160) @30fps
Video Playing Format
MP4, M4V, 3GP, 3G2, WMV, ASF, AVI, FLV, MKV, WEBM
Video Playing Resolution
UHD 4K (3840 x 2160) @60fps
Audio Playing Format
MP3, M4A, 3GA, AAC, OGG, OGA, WAV, WMA, AMR, AWB, FLAC, MID, MIDI, XMF, MXMF, IMY, RTTTL, RTX, OTA, DSF, DFF

Camera

Main Camera
Single
Front Camera
Single
Main Camera - Resolution
12 MP, Dual Pixel F1.7 OIS
Front Camera - Resolution
8 MP, CMOS F1.7
Main Camera - Flash
Yes
Front Camera - Flash
No
Main Camera - Auto Focus
Yes
Front Camera - Auto Focus
Yes

Connectivity

ANT+
Yes
USB Version
Type C
Location Technology
GPS, GLONASS, Beidou, Galileo
Headphone Socket
3.5mm Stereo
MHL
No
Wi-Fi
Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz), VHT80 MU-MIMO, 1024QAM
Wi-Fi Direct
Yes
DLNA Support
No
NFC
Yes
Bluetooth Version
Version 5.0
Bluetooth Profiles
A2DP, AVRCP, DI, HFP, HID, HOGP, HSP, MAP, OPP, PAN, PBAP
PC Sync.
Samsung Smart Switch

Battery

Standard Battery Capacity
3500mAh
Removable
No
Fast charging
No
Internet Usage Time(3G)
Up to 13h
Internet Usage Time(LTE)
Up to 15h
Internet Usage Time(Wi-Fi)
Up to 15h
Video Playback Time
Up to 18h
Audio Playback Time
Up to 78h
Talk time
Up to 24h
